Power 400 Watt 2-Channel Amplifier T400-2

The Power T400-2 is a 2-channel amplifier capable of producing 200 Watts into each channel at 2-Ohms. The T400-2 is so powerful it can easily drive multiple component systems or multiple subwoofers in bridged/mono mode.

Read More
0 Reviews
Discontinued
Overview

The T400-2 is "One of the most impressive amps I've ever seen." says Sergey of K&B Audio. Don't let its size fool you ... this all MOSFET amp packs enough power to run one 2-Ohm DVC or two 4-Ohm DVC subwoofers with ease and its dual function EQ can tune-in any pair of high frequency component speakers to deliver premium sound quality. "The amplifier is without a doubt the most efficient Class A/B amplifier I've ever tested."

  • 24dB/octave crossover
  • MOSFET power supply
  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • Audiophile grade speaker connections
  • RCA pass-thru outputs
  • 2 Year Warranty
Technologies
Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Learn more
x
Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more
x
DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.

Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more
x
Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.

DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

Learn more
x
DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

Learn more
x
MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Learn more
x
NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.

CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
x
CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.

Punch EQ2
Punch EQ2

Onboard equalizer with up to +18dB @ 45Hz and/or up to +12dB boost at 12kHz.

Learn more
x
Punch EQ2
Punch EQ2

Onboard equalizer with up to +18dB @ 45Hz and/or up to +12dB boost at 12kHz.

TO-247 MOSFETs
TO-247 MOSFETs

(left-OLD | right-NEW)
Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more ...

Learn more
x
TO-247 MOSFETs
TO-247 MOSFETs

(left-OLD | right-NEW)
Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more metal tab area for more power capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in competitor amps.

TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the ...

Learn more
x
TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the signal to travel through the amplifier at a lower voltage. The result is greater reliability and exceptional sound quality.

Specifications
CEA-2006 Compliant
CEA-2006 Power Rating
120W x 2 @ 4Ω
≤1.0% THD+N
Number of Channels
2
Total Power
(Sum of Rated Power)
400 Watts RMS
Rated Power
(RMS Continuous Power)
120 Watts x 2 @ 4-Ohm
200 Watts x 2 @ 2-Ohm
400 Watts x 1 @ 4-Ohm Bridged
2-Ohm x 1 Bridged Stable
Dynamic Power
(PVC/PowerCube®)
145 Watts x 2 @ 4-Ohms 0° Res
243 Watts x 2 @ 2-Ohms 0° Res
Bridgeable
Yes
Frequency Response
20Hz to 20kHz +/- 1dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class A/B
Efficiency (average)
76% @ 4-Ohm
71% @ 2-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Low level: 1 RCA pair
Signal Output
Low level: 1 RCA pair
Tone Controls
Treble: 0dB to +12dB @ 12kHz
Bass: 0dB to +18dB @ 45Hz
Crossover Controls
High-Pass (HP): 50-500Hz 24dB/octave Butterworth
Low-Pass (LP): 50-500Hz 24dB/octave Butterworth
Remote Controls
Optional Remote Punch EQ
(overrides built-in Punch EQ)
Visual Indicators
Power
Thermal
Protect
Power Wire Gauge
8 AWG to 4 AWG
Power Input Connector
Block
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Screw terminal barrier strip
Cooling
Convection
Heatsink
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
60 A
Average Current Draw (13.8V Music)
30 A
Max. Current Draw (13.8V Sinewave)
60 A
Suggested Alternator
75 A
Dimensional Diagram
Dimensions (H x W x D)
2.14 x 8.14 x 11.41 (in)
5.42 x 20.68 x 28.97 (cm)
Shipping Weight
10.29 Lbs. (4.66 Kg.)
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.





















Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
