Compact Digital Media Receiver w/ 2.7" Display PMX-3

Three Quarter Beauty Shot of Media Receiver with Display
Front View of Media Receiver with Display
Back View of Media Receiver with Display
Three Quarter Beauty Shot Back View of Media Receiver with Display
Right Side View of Media Receiver with Display
Three Quarter Beauty Shot of Products Included in Kit
Left Side View of Media Receiver with Display
Aerial View of Media Receiver with Display
Media Receiver with Display Installation View

Compact Digital Media Receiver w/ 2.7" Display PMX-3

The PMX-3 is a ground up designed digital media receiver for marine and motorsports applications with full color 2.7" TFT display. This unit not only has the functionality you desire such as a custom designed GUI interface and menu system built with "ease of use" in mind, but also features SiriusXM tuner compatibility, Pandora radio control via USB or Bluetooth and full iPhone support with folder browsing capability.

Software Downloads PMX-3 | Software Updates

Read More
0 Reviews
$449.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

The PMX-3 compact digital media receiver, designed for marine and motorsports applications, features a 2.7"full color TFT display for optimum viewing even in full sun that is optically wet bonded to prevent any dust or moisture penetration.

The PMX-3 is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such SiriusXM tuner compatibility, Pandora control capabilities and Bluetooth audio steaming with album art support1, this unit becomes a true command center of any system. Output flexibility comes with a 4x50 @ 2ohm internal amplifier or front and rear/sub output RCA's allowing the addition of aftermarket amplifiers for more power and output.   1Android devices equipped with limited functionality. Please refer to owners manual for details.

We've also upgraded the unit to feature a reverse camera composite video input with reverse trigger control and a day/ night display mode for better viewing in low light conditions. Finally, add in the EEprom memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you'll ever need.

FEATURES AT A GLANCE

  • 2.7" Full color Thin Film Transistor display
  • Wired remote ready (up to 3 remotes)
  • SiriusXM-Ready™ (SXV300 module) with color channel logos (18 channel presets)
  • Two-piece mounting system to secure panel to mounting surface
  • Upgradeable Firmware and Bluetooth Software via USB
  • Internal power amplifier 4x45W 2Ω stable
  • IPX6 Marine Grade for prevention of water intrusion
  • Rear AUX-In (L/R)
  • ASTM: B117 Salt Fog & D4329 UV Exposure Tested
  • Integrated voltage gauge w/ low voltage alert
  • Electrically Erasable Programmable Read-Only Memory (EEPROM) is a type of non-volatile memory used in electronic devices to store data that must be saved when power is removed
  • Front Panel Sub Control
  • Licensed Pandora control (Apple direct USB or BT/Android via Bluetooth)
  • Bluetooth streaming audio (A2DP) protocol version 1.4 installed
  • Automotive grade AM/FM Radio, Weatherband Radio digital tuner. Supports Radio Data System (RDS) to receive broadcast information
  • Simple Secure Pairing (SSP)
  • Rear USB With 1A Charging Only
  • Made for iPhone apple certified
  • Folder browsing via BT connected iPhones
  • Selectable crossover slopes of 12dB or 24 dB for each zone
  • Single Zone output with 2 channels front full range and 2 channels rear/ subwoofer selectable rated at 2 volt
  • Display album art from connected iPhones on the radio display
  • Selectable high pass and low pass crossover points for each zone
  • Dedicated DSP audio processors for each zone with independent 7 Band EQ + Punch EQ
  • Waterproof Rotary Encoder Volume Control
  • Adjustable input gain for each source
  • White LED Button Illumination
  • Tactile convex buttons for easy identification
  • Wired and front panel illumination control
  • Wet Bonded Display
  • Epoxy coated circuit board for water resistance
  • Direct composite video input connection
  • 2-Year Warranty
  • External trigger input to activate reverse camera mode
  • Day/Night display mode
Videos
Technologies
SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Learn more
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

Learn more
Made for Android

This device supports the Google "Made for Android" protocol.

Learn more
Built In Bluetooth®

Built In Bluetooth®

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
Element Ready™ | Source Units

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Learn more
FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that ...

Learn more
Specifications
Clock
(Yes/No)
No
Steering Wheel Control Ready
(Yes/No)
No
Multi-Zone/Multi-Source
(Yes/No)
No
SiriusXM-Ready®
(Yes/No)
Yes
Speaker Outputs
(Yes/No)
Yes
Apple®/Android™ Compatible
(Yes/No)
Yes
Limited functionality on Android. See owners manual.
FEATURES

USB Charging
(Yes/No)
Yes
Bluetooth®
(Yes/No)
Yes
3.0+EDR, A2DP 1.3
Pandora® Internet Radio
(Yes/No)
Yes
TUNER

AUX Input
(Yes/No)
Yes (1pr)
FM TUNER
Frequency Range
87.5 MHz - 107.9 MHz
TUNER
Number Of Presets
18 FM / 12 AM / 6 WB
AM TUNER
Frequency Range
530 kHz - 1710 kHz
FM TUNER
Sensitivity
8 dB
AM TUNER
Usable Sensitivity
40 dB
RCA Output Voltage
2V RMS
Does not clip at full output
RCA OUTPUTS
(1 pr) Front
(1 pr) Rear (or Sub-out)
WB TUNER
Frequency Range
162.40 - 162.55
(US & Canada)
RCA Output Impedance
500Ω
SPEAKER OUTPUTS

Speaker Impedance
2-Ohms
Power Output
CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω Peak
≤1.0% THD+N
GENERAL

Device Type
Digital-Media Receiver
Frequency Response
20 Hz - 20 kHz
MEDIA PLAYER
Audio Format Compatibility
MP3
WMA
FLAC
Made for iPod Models
iPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Made for iPhone Models
iPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
Android Compatibility
Bluetooth® Only
USB Capacity
32Gb max
999 Folders max
999 Songs max
USB Version
2.0
USB Output Current
1A
Compatible Remotes
PMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
Operating Voltage
10.5 V - 16 V
Display Size
2.7” Color TFT
Back Panel Cutout
3" (77mm)
Fuse Rating
20 A
Dimensions (HxWxD)
Width 4.5" (11.5cm)
Face Depth 1.5" (3.8cm)
Mount Depth 2.9" (7.4cm)
Height 4.2" (10.6cm)
Shipping Weight
3.1 Lbs. (1.41 Kg)
