Punch Marine 6.5" Full Range Speakers PM2652

The PM2652 is a Punch 6.5" 2-way component system with a coaxially mounted tweeter featuring marine grade weather proofing technologies. Supplied in all white or black with a stainless steel sport grille.

• This model replaced by the m2-65

Read More
0 Reviews
Discontinued
Overview

The PM2652 6.5" Element Ready speaker features a 1" coated aluminum dome tweeter that is bridge mounted over a mineral filled, polypropylene cone midrange with integrated UV inhibitors. The cone is attached to the Centrex® Plastic injection molded frame by a Thermo-Plastic Elastomer (TPE) surround and moisture, tear and fatigue resistant Aramid fiber spider assembly. This is driven by our matched motor magenetics structure with integrated aluminum heat sinking shorting ring for maximum excursion and output. Additionally, the speaker features fully insulated flex lead wires, corrosion resistant gold plated speaker terminals with integrated expansion connections for our PM2T-S tweeter kit and a fully sealed 12dB/ Octave crossover. The entire system is topped off with an 18 gauge stainless steel and Centrex® plastic grill assembly using stainless steel hardware.

FEATURES AT A GLANCE

  • Integrated aluminum heat sinking shortening ring (IDHS)
  • UV and Salt-Fog resistant TPE (Thermo-Plastic Elastomer) surround
  • UV stable Centrex™ 814 injection molded plastic parts
  • Fully insulated flex lead wire stitched under spider
  • Available in black or white
  • Spare terminal set for optional additional tweeters
  • Moisture, tear and fatigue resistant Aramid fiber spider
  • Linear, high excursion matched motor magnetics and suspension design
  • Integrated 12dB/octave sealed crossover with integrated protection circuit
  • 1" (25mm) bridge mounted component grade coated aluminum alloy tweeter
  • 18 gauge corrosion resistant removable Stainless Steel grille cover insert
  • True Marine Grade compliance
  • Corrosion resistant gold plated polarized input terminals
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • 2-Year Warranty
Technologies
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
FlexFit Basket - Marine

The slot mounted frame pattern allows fine-tuning of the marine speaker's mounting position.

Learn more
Element Ready™ | Speakers

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Learn more
ASTM Test Standards

Marine Grade standards ensure resistance to extreme environments.

Learn more
ICC Crossover

The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier ...

Learn more
Specifications
Speaker Type
2-Way Coax
Midrange Size
(Nominal Diameter)
6.5"
Crossover
High-Pass (HP): 12dB
Shipping Weight
Sensitivity
(dB @ 1W/1M)
89
Grille/Trim Ring Included
Yes
Frequency Response (Hz)
49Hz - 22kHz
Mounting Hardware
Stainless Steel
Midrange Mounting Depth
2.8 in. (7.1 mm)
Nominal Impedance (Ohms)
4-Ohm
Tweeter Size
(Nominal Diameter)
1" (25 mm)
Power Handling (RMS)
85 Watts RMS
170 Watts Max
CEA-2031 Compliant
CEA-2031 Guidelines
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.
