Punch Marine Compact AM/FM/WB Digital Media Receiver 2.7" Display PMX-2

The PMX-2 is an AM/FM/WB tuner and compact digital media receiver with a 2.7" full color display.

Software Downloads PMX-2 | Software Updates

Read More
3 Reviews
$419.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

The PMX-2 compact digital media receiver is designed for marine and motorsports applications.

The PMX-2 features a 2.7"full color TFT display for optimum viewing - even in full sun - that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such Pandora control capabilities and Bluetooth audio steaming with album art support1 this unit becomes a true command center of any system. 1Android devices equipped with limited functionality. Please refer to owners manual for details.

Output flexibility comes with a 4x50W @ 2ohm internal amplifier or front and rear/sub output RCA's allowing the addition of after-market amplifiers for more power and output. Add-in the EEPROM memory system, custom GUI interface, and wired remote expansion capabilities and you have the only media receiver you'll ever need.

FEATURES AT A GLANCE

  • Pandora Internet Radio
  • AUX and USB Inputs with USB Charging
  • ISO8846/SAE J1171 Ignition Protection Certified
  • A2DP and AVRCP Bluetooth Wireless Streaming
  • FCC, CE, IC, and C-Tick Certified
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • 7-Band Graphic EQ
  • AM/FM/WB Tuner
  • IPX6 Marine Grade for prevention of water intrusion
  • Independent Subwoofer Level Control
  • iPod playback with on-screen display
  • Low Voltage Warning Alert
  • Multi-region radio frequencies
  • 2-Year Warranty
  • On Board Punch EQ Control
  • 2.7" full color display w/ auto dimming backlightning
  • Zone Control: 1 Zone / 1 Source (F/R or Sub)
  • *Antenna not included
Technologies
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
Built In Bluetooth®

Built In Bluetooth®

Learn more
Made for Android

This device supports the Google "Made for Android" protocol.

Learn more
ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

Learn more
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that ...

Learn more
Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Learn more
Element Ready™ | Source Units

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Specifications
FM TUNER
Sensitivity
8 dB
AM TUNER
Frequency Range
530 kHz - 1710 kHz
AM TUNER
Usable Sensitivity
40 dB
RCA Output Voltage
2V RMS
Does not clip at full output
RCA Output Impedance
500Ω
Operating Voltage
10.5 V - 16 V
Speaker Impedance
2-Ohms
Fuse Rating
20 A
Dimensions (HxWxD)
Width 4.5" (11.5cm)
Face Depth 1.5" (3.8cm)
Mount Depth 2.9" (7.4cm)
Height 4.2" (10.6cm)
USB Capacity
32Gb max
999 Folders max
999 Songs max
MEDIA PLAYER
Audio Format Compatibility
MP3
WMA
FLAC
TUNER
N/A
Compatible Remotes
PMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
Android Compatibility
Bluetooth® Only
Device Type
Digital-Media Receiver
SPEAKER OUTPUTS
Yes
Pandora® Internet Radio
(Yes/No)
Yes
Bluetooth®
(Yes/No)
Yes
3.0+EDR, A2DP 1.3
WB TUNER
Frequency Range
162.40 - 162.55
(US & Canada)
TUNER
Number Of Presets
18 FM / 12 AM / 6 WB
USB Version
2.0
USB Charging
(Yes/No)
Yes
Steering Wheel Control Ready
(Yes/No)
No
Frequency Response
20 Hz - 20 kHz
Multi-Zone/Multi-Source
(Yes/No)
No
FM TUNER
Frequency Range
87.5 MHz - 107.9 MHz
Power Output
CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω Peak
≤1.0% THD+N
Clock
(Yes/No)
No
Speaker Outputs
(Yes/No)
Yes (4-channel)
Made for iPod Models
iPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
RCA OUTPUTS
(1 pr) Front
(1 pr) Rear (or Sub-out)
Display Size
2.7" Color TFT
SiriusXM-Ready®
(Yes/No)
No
USB Output Current
1A
FEATURES
N/A
Made for iPhone Models
iPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
Apple®/Android™ Compatible
(Yes/No)
Yes
Limited functionality on Android. See owners manual.
AUX Input
(Yes/No)
Yes (1pr)
GENERAL
N/A
Back Panel Cutout
3" (77mm)
Shipping Weight
3 Lbs. (1.36 Kg)
