M2D2-10S

M2 10" DVC 2Ω Color Optix™ Sealed Enclosure Marine Subwoofer M2D2-10S

The M2D2-10S is a 10” DVC 2-Ohm Color Optix™ subwoofer that connects with our Rockford Fosgate Color Optix™ controller and RF Connect™ App, allowing you to customize your own color patterns. Connectivity is handled through integrated Deutsch™/Amphenol™ connectors that make wiring simple and error proof. Wiring with the Versa Switch™ allows you to quickly configure the voice coil in series or parallel with flip of switch. This “S” model is optimized for small sealed enclosures where space is at a premium. Includes 2-piece grille with interchangeable colored plastic and stainless-steel insert.

Read More
0 Reviews
$349.99
+
Overview

The M2 series of Element Ready™ subwoofers are IP67 certified, making them truly purpose-built for marine and motorsport applications where protection from damaging UV rays and water spray is essential. They are designed to pair with the Rockford Fosgate Color Optix™ controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. To compliment the plug and play connectivity and streamline installation, M2 subwoofers are equipped with a Versa Switch™ to make changing impedance between 1 and 4 ohms as easy as flipping a switch. Matching the theme of your boat can be further customized by using the included color insert or stainless-steel grille for that sport look.

  • Adjust color experience to suit your taste with Rockford Fosgate® Color Optix™ controller (optional)
  • Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
  • VERSA impedance switch quickly allows series or parallel configuration without additional wiring
  • Optimized for small sealed enclosures when there is very little space for an enclosure
  • Element Ready™ design protects against outdoor exposure
  • IPX6 Marine Grade for prevention of water intrusion
  • Ultra-bright wide-angle RGB LEDs provide rich, reliable illumination
  • Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
  • Deutsch™ connector front/rear silicone seal protects against water ingress
  • VAST vertical attach surround technique increases effective radiating cone area up to 25%
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
  • Gold plated Marine grade brass terminals provide a corrosion resistant connection
  • 2-piece grille allows for interchangeable stainless-steel or "sport" option
  • Provides superb low and midrange frequency reproduction with a smoother high frequency roll off
  • Klippel Verified certification program delivers the best possible speakers
  • 2-Year Warranty
Videos

Color Optix™ Experience

Experience the Color Optix™ speaker and subwoofer line from Rockford Fosgate. Designed for watercraft of all kinds, they are Element Ready to withstand water, salt, and UV rays.

Color Optix™ Speakers Overview

In this video, we'll break down our all-new Color Optix™ speakers and subwoofers, that are designed to light the way.

Color Optix™ Controller Overview

The PMX-RGB Color Optix™ controller provides LED lighting control over M1 & M2 speakers and subwoofers. This allows you to create a true marine ecosystem that works together seamlessly. Pair this with our RF Connect™ smartphone app and give your system infinite control by customizing the color and lighting effects of your speakers. Supports up to 8 speakers or subwoofers. App supports multiple Color Optix™ controllers.

Technologies
Element Ready™ - Subwoofers
Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

Learn more
x
Element Ready™ - Subwoofers
Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

VAST Surround - Marine
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
x
VAST Surround - Marine
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

VERSA Switch
VERSA Switch

Allows you to easily switch Dual Voice Coils into a Series or Parallel configuration.

Learn more
x
VERSA Switch
VERSA Switch

Allows you to easily switch Dual Voice Coils into a Series or Parallel configuration.

IPX6 Water Intrusion Rating
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
x
IPX6 Water Intrusion Rating
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

ASTM B117 Testing
ASTM B117 Testing

ASTM B117 500Hr Salt/Fog Testing Standards

Learn more
x
ASTM B117 Testing
ASTM B117 Testing

ASTM B117 500Hr Salt/Fog Testing Standards

ASTM G154 Testing
ASTM G154 Testing

ASTM G154 500Hr Accelerated UV testing

Learn more
x
ASTM G154 Testing
ASTM G154 Testing

ASTM G154 500Hr Accelerated UV testing

Klippel Verified
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
x
Klippel Verified
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

ISO60068-2-64 Testing
ISO60068-2-64 Testing

ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on watercraft ...

Learn more
x
ISO60068-2-64 Testing
ISO60068-2-64 Testing

ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on watercraft and motorsport applications.

Specifications
Size
10"
Nominal Impedance (Ohms)
1-Ohm or 4-Ohm Switchable
Power Handling (Watts RMS)
400 Watts
Voice Coil Diameter
1.95" (49.53 mm)
Voice Coil Type
Dual Voice Coil
Magnet Weight (oz)
32.9 oz. (0.9 Kg)
Fs (Hz)
28
Re (Ohms)
3.3
Le (mH)
3.43
Sd (cm2)
363
Qms
4.48
Qes
0.91
Sealed Box Volume (Vb)
0.5 cu. ft. (14 Liters)
Qts
0.75
Vas
36.4
SPL (dB @ 1w/1m)
86
Xmax (mm)
12.0
Woofer Displacement
0.06 cu. ft. (1.74 Liters)
Speaker Connector
Deutsch™ and 1/8" Spade
Cutout Diameter
8.87" (225.3 mm)
Mounting Depth
4.24" (107.7 mm)
Shipping Weight
8.5 Lbs. (3.85 Kg)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
