Power 750 Watt Class-bd Mono Element Ready™ Amplifier TM750X1bd

The TM750X1bd is a very powerful compact 750 watt mono amplifier stable to 1-ohm.  The amplifier features our Class-bd topology for maximum power, sound quality and efficiency for low frequency amplifiers. It also integrates our patented Constant Power technology which results in up to 25% more output power. Top mounted controls feature our patented C.L.E.A.N. circuit to easily set your gains, integrated low-pass crossover, and our famous Punch EQ.



The amplifier also features high and low level inputs combined with our differential inputs to eliminate incoming noise.  It can also provide a remote-out trigger when using high level inputs. Dual fan cooling, real time thermal monitoring and dual extruded heat sinks maintain heat dissipation even at high outputs keep the amp cool.



In addition to the conformal coated pc boards, the Element Ready™ design ads protection against water, dust and UV rays, making it great for multiple applications where it could be exposed to harsh outdoor environment.

Read More
1 Review
Discontinued
Overview

The Power TM750X1bd 750 Watt mono, ultra-compact amplifier is built on Rockford Fosgate’s patented Class bd technology platform. This design creates a highly efficient design that reduces the electrical impact on the vehicles charging system by using the efficient Class D technology while maintaining fidelity combining it with Class B topology. Flexible vehicle integration is achieved via a configurable input harness with Molex style connectivity that accepts both RCA and speaker level signals while our differential input circuitry eliminates signal noise from entering the amplifier resulting in a clean audio signal.

When using speaker level input signals, the amplifier also has integrated auto turn-on capabilities and converts its remote input terminal to an output that can be used to turn-on additional amplifiers. This can eliminate the need of sourcing a separate remote turn-on signal for the amplifier from the vehicle. Top mounted controls allow easy access to the built-in low pass crossover, patented Punch EQ boost circuit and our patented C.L.E.A.N. input/output clip detection circuits.

The 3-stage thermal lock extrusion with dual fan forced induction keeps everything cool while our real-time thermal/protection schemes safeguard the amplifier in the event of overheating or short circuit conditions. The unit is also compatible with our Punch PLC2 remote level controller and is ideal for those installations where you need a compact amplifier that can produce high output power.

FEATURES AT A GLANCE

  • 8 AWG spring compression wiring terminal
  • Class-BD technology provides 75-80% efficiency over traditional class A/B designs
  • Top mounted controls
  • 2013 PLC2 remote ready
  • Upgraded RCA connectors
  • Rockford Fostgate proprietary low impedance constant power
  • CEA-2006 and CE Compliant
  • AP remote out feature when using high level inputs
  • Discrete surface mount technology
  • Marine grade two part epoxy coating on circuit boards
  • Differential inputs with high level auto turn-on feature
  • 2-Year Warranty
  • All other Rockford protection schemes
  • C.L.E.A.N. input/output clip detection and indicator LEDs
  • Dual extruded heat sinks
  • Real time thermal sensing
  • Dual fan cooled
Technologies
C.L.E.A.N. Set-Up

C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help ...

Learn more
Class-BD

Class-BD amplifiers have 75-80% efficiency ratings vs. 20-60% efficiency ratings of traditional Class-A/B amplifiers.

Learn more
Constant Power

Constant Power is a patented circuit topology that provides instantaneous delivery of output power over varying ...

Learn more
CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
Element Ready™ | Amps

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
3-Stage Airflow

3-stage airflow method effectively exhausts heat and ensures your amplifier runs cooler for optimum performance.

Learn more
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more
Specifications
Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
750 Watts
Rated Power
(RMS Continuous Power)
500 Watts x 1 @ 4-Ohm
750 Watts x 1 @ 2-Ohm
750 Watts x 1 @ 1-Ohm
Dynamic Power
(PVC/PowerCube®)
538 Watts x 1 @ 4-Ohm
909 Watts x 1 @ 2-Ohm
990 Watts x 1 @ 1-Ohm
Bridgeable
No
Frequency Response
20Hz-230Hz +/-1dB
Input Sensitivity
150 mV to 12 V
Circuit Topology Class
Class BD
Efficiency (average)
>85%
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
High/Low Level Input: 4-Pin harness
Signal Output
-
Tone Controls
Bass: 0 to +18 dB @ 45 Hz
Crossover Controls
Low-Pass: 50Hz - 250Hz @ 12dB/Octave Butterworth
Infrasonic: 28Hz @ 12dB/Octave Butterworth
Remote Controls
Optional PLC2 provides Punch Level Control
Visual Indicators
Power: Blue LED
Protect: Red LED
Input Clip: Red LED3
Output Clip: Blue/Violet/Red LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Power Wire Gauge
8 AWG
Power Input Connector
Detachable Compression Terminal
Replacement 1040-57997
Speaker Wire Gauge
10 AWG
Speaker Output Connector
High/Low Level Input: 4-Pin harness
Cooling
Dual Fan Cooled
Heatsink
Extruded Aluminum
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
100 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
Suggested Alternator
Included In The Box
Dimensions (H x W x D)
1.6 x 4.3 x 8.3 (in.)
4.1 x 10.8 x 21.1 (cm)
Shipping Weight
3.44 Lbs. (1.56 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

The below diagrams optimize this amp for its lowest recommended MONO load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
