Power 400 Watt Class-ad 4-Channel Element Ready™ Amplifier TM400X4ad

The TM400X4ad is a powerful and compact 400 Watt 4-channel amplifier.  The amplifier features our proprietary high efficiency Class-ad topology for maximum power, sound quality and efficiency in full-range amplifier. It also integrates our patented Constant Power technology which results in up to 25% more output power. Top mounted controls feature our patented C.L.E.A.N. circuit to easily set your gains, integrated low-pass crossover, and our famous Punch EQ.



The amplifier also features high and low level inputs combined with our differential inputs to eliminate incoming noise.  It can also provide a remote-out trigger when using high level inputs. Dual fan cooling, real time thermal monitoring and dual extruded heat sinks maintain heat dissipation even at high outputs keep the amp cool.



In addition to the conformal coated pc boards, the Element Ready™ design ads protection against water, dust and UV rays, making it great for multiple applications where it could be exposed to harsh outdoor environment.

Read More
2 Reviews
SALE
$349.99 $569.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

The Power TM400X4ad 400 Watt 4-channel ultra-compact, amplifier is built on Rockford Fosgate’s proprietary Class-AD technology, featuring Constant Power to produce the same output at both 4-Ohm and 2-Ohm impedances. Flexible vehicle integration enabled through low-level and high-level inputs with auto turn-on. Top mounted controls allow easy access to built-in crossover and C.L.E.A.N. input/output clip detection circuits. The 3-stage thermal lock extrusion with dual fan forced induction keeps everything cool while real-time thermal/protection schemes safeguard the amplifier.

FEATURES AT A GLANCE

  • Rockford Fosgate proprietary Class AD technology
  • 8 AWG power/ground connector w/ upgraded RCA connectors
  • Remote-Out feature when using high level inputs
  • C.L.E.A.N. input/output clip detection and indicator LEDs
  • Differential inputs with high level auto turn-on feature
  • Dual extruded heat sinks
  • 4/2 Ohm muti-impedance Constant Power
  • Discrete surface mount technology
  • Top mounted controls
  • Real time thermal sensing
  • Dual fan cooled
  • 4 Ohm bridged capable
  • 2/4 channel input switch
  • 2-Year Warranty
  • Marine grade two part epoxy coating on circuit boards
Technologies
3-Stage Airflow

3-stage airflow method effectively exhausts heat and ensures your amplifier runs cooler for optimum performance.

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more
CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
Constant Power

Constant Power is a patented circuit topology that provides instantaneous delivery of output power over varying ...

Learn more
Class-AD

This technology allows the amplifier to produce more power with less current draw from the vehicle's ...

Learn more
C.L.E.A.N. Set-Up

C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help ...

Learn more
Element Ready™ | Amps

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Specifications
Cta-2006 Compliant
Number of Channels
4
Total Power
(Sum of Rated Power)
400 Watts
Rated Power
(RMS Continuous Power)
100 Watts x 4 @ 4-Ohm
100 Watts x 4 @ 2-Ohm
200 Watts x 2 @ 4-Ohm Bridged
Dynamic Power
(PVC/PowerCube®)
128 Watts x 4 @ 4-Ohm
152 Watts x 4 @ 2-Ohm
290 Watts x 2 @ 4-Ohm Bridged
Bridgeable
Yes
Front Terminals: Left (+) Right (-)
Rear Terminals: Left (+) Right (-)
Frequency Response
20Hz-20kHz +/-1dB
Input Sensitivity
150 mV to 12 V
Circuit Topology Class
Class AD
Efficiency (average)
>75%
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Front High/Low Level Input: 4-Pin harness
Rear High/Low Level Input: 4-Pin harness
Signal Output
Tone Controls
Treble: 0 to +14 dB @ 12.5 kHz
Bass: 0 to +18 dB @ 45 Hz
Crossover Controls
High-Pass:
50Hz-250Hz @ 12dB/Octave Butterworth
Low-Pass:
50Hz-250Hz @ 12dB/Octave Butterworth
All-Pass: Yes
Remote Controls
Visual Indicators
Power: Blue LED
Protect: Red LED
Input Clip: Red LED3
Output Clip: Blue/Violet/Red LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Power Wire Gauge
8 AWG
Power Input Connector
Detachable Compression Terminal
Replacement 1040-57997
Speaker Wire Gauge
16 AWG
Speaker Output Connector
Front: 4-Pin Harness
Rear: 4-Pin Harness
Cooling
Dual Fan Cooled
Heatsink
Extruded Aluminum
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
60 A
Average Current Draw (13.8V Music)
28 A
Max. Current Draw (13.8V Sinewave)
55 A
Suggested Alternator
75 A
Included In The Box
Dimensions (H x W x D)
1.6 x 4.3 x 8.3 (in.)
4.1 x 10.8 x 21.1 (cm)
Shipping Weight
3.4 Lbs. (1.54 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

The below diagrams optimize this amp for its lowest recommended BRIDGED/MONO load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Wiring Kits

ARE YOU ENGINEERED TO ROCK?

Get a 1-Year extended amplifier warranty when using a matching Rockford Fosgate installation kit.

We want you to get the maximum performance and reliability from your Rockford Fosgate amplifier. We're so certain using the right cables make a difference, we'll give you and additional 1-Year amplifier warranty when using a matching installation kit!

  • 1 Purchase a Rockford Fosgate Punch or Power amplifier.
  • 2 Add the correct amplifier installation kit.
  • 3 Get an additional 1 year amplifier warranty FREE!

Reviews

Purpose Built

No introduction needed. As small as a smartphone and powerful enough to run a smart car!

Just installed

I just installed this on my 2011 Street Glide weekend and the improvement in the sound quality is great. I have noticed a big difference in the level of the volume between the radio, Bluetooth streaming from my phone, the thumb drive, and satellite radio. The radio and satellite radio sound is too loud on volume level 18-20. When I stream from my phone or play a thumb drive I have to turn up the volume level up to 30 -40 to match the volume of the radio. Also, I am a little worried that the amplifier gets very hot to the touch and the fan has not turned on. I will let you know if this becomes an issue. Very easy to install. They recommend using 8 gauge wire for the hot and ground wire. It's a little difficult to work with if you use "True" 8 gauge OFC wire. especially try to connect the hot and ground to the adapter that fits into the amplifier.
