Power 10" T2 Slim 2Ω SVC Subwoofer for Sealed Enclosures T1S2-10S

Front View of Subwoofer with Trim Ring
Three Quarter Front of Subwoofer with Trim Ring
Side View of Subwoofer with Trim Ring
Three Quarter Back of Subwoofer with Trim Ring
Profile View of Subwoofer with Trim Ring

Power 10" T2 Slim 2Ω SVC Subwoofer for Sealed Enclosures T1S2-10S

The re-engineered T1 Slim subwoofer series delivers next-level reliability and tactile bass performance, offering improved responsiveness and exceptional thermal management. Available in both sealed and ported options, these subwoofers are designed for the tightest installations, while still providing all the bass you demand.

Sound of Surround – Utilizing Nano Cell Direct injection and a bonded co-molded surround, the T1 series subwoofers ensures maximum reliability and high efficiency low end bass extension.

VCCF (Voice Coil Composite Former) – The voice coil is the heart of any speaker, and ours is crafted from a specialized composite material rigorously tested to withstand extreme heat and low thermal conditions, ensuring no-quit power and minimal motor distortion.

Dual Spiders – The voice coil carrier features a asymmetric aligned 2-spider design to deliver enhanced bass response. Each spider works together to handle a range of low-end notes, ensuring you never miss any bass hits in your music.

Perfect Fit – Available in multiple options, including sealed and ported options, these subwoofers make it easy to find the perfect fit for any installation, no matter the space.

Click to watch video Launch Video
Click to watch video Product Overview

Read More
0 Reviews
NEW
$449.99
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

MAX BASS, SLIM SPACE

This Gen-2 version of Rockford Fosgate’s "T1 Slim" subwoofer is designed to deliver big bass in a compact, shallow design. It’s been re-engineered with more mass to fit in smaller enclosures and includes upgrades like a new surround and better heat management.  The “S” sealed version is designed for smaller sealed enclosures and work best in closed environments (truck cab).



The voice coil now uses pure copper wire for better conductivity, paired with a new composite former to dissipate heat and reduce distortion. Additionally, an aluminum spider spacer improves cooling.  The suspension utilizes a new polymer surround, made using an advanced NCDI (Nano Cell Direct Injection) process to enhance efficiency and durability without risking dry-rot.

FEATURES AT A GLANCE

  • Supercritical synthetic organic polymer surround
  • Linear Carbon Fiber/PMI/Glass Fiber cone with aluminum dustcap
  • Chemically bonded co-molded surround for a stronger attachment
  • Symmetrical ultra-flexible braided flat tinsel leads resistant to fatigue
  • Dual Nomex progressive spiders with stitched tinsel leads
  • Dual wound single 2.5" pure copper voice coil with interior and exterior coils
  • High temp, high energy Neodymium motor structure
  • Diecast aluminum frame with integrated heat sink fins
  • Custom 10 AWG slot loaded brass push spring terminals with corrosion resistant tin plating
  • Detachable die cast aluminum trim ring
  • Optional protective grille insert available
  • Optimized for compact sealed enclosures
  • 1 Year Warranty
Videos
Technologies
CTA-2031

Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards.

Learn more
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
IDHS™ Inductive Damping Heat Sink

Secures directly to the top of magnet structure to improve system efficiency by reducing both distortion ...

Learn more
Split Yoke Motor Technology

The unique motor structure design allows full excursion capabilities of the woofers voice coil while allowing ...

Learn more
Encapsulated Voice Coil Coupling

Our EVCC (Encapsulated Voice Coil Coupling) technology connects to the woofers voice coil from both the ...

Learn more
VAST Surround - Subs

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
FlexFit Basket - Subwoofer

The slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position.

Learn more
Stitched Tinsel Leads

Improved reliability and performance by reducing fatigue and possible shorting.

Learn more
Specifications
CEA-2031 Compliant
CEA-2031 Guidelines
Size
10"
Subwoofer Type
Shallow
Nominal Impedance
Re (Ohms)
1.8
Fs (Hz)
36
Qms
7.0
Qes
0.86
Qts
0.76
Sd (cm2)
356
Vas (Liters)
15.4
Le (mH)
0.71
Xmax (mm)
15
SPL (dB @ 1w/1m)
82
Power Handling (Watts RMS)
500 Watts RMS
1000 Watts Max
Voice Coil Type
Single Voice Coil
Voice Coil Diameter
2.5" (63.5mm)
Magnet Weight (oz)
15.1 oz. (0.43 Kg)
Speaker Connector
10 AWG slot loaded
Cutout Diameter
9.13 in. (232 mm)
Mounting Depth
3.01 in. (76.5 mm)
Woofer Displacement
0.028 cu. ft. (0.82 Liters)
Sealed Box Volume (Vb)
0.5 – 0.75 cu.ft. (14.2 – 21.2 Liters)
Vented Box Volume (Vb)
In The Box
(1) 1125-73494-01 Bit Driver, 40mm 5.0mm
(4) 1125-80626-01 4mm Hex, M5x43mm
(8) 1125-80626-01 4mm Hex, M5x43mm Self Tap
Shipping Weight
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
