FM/AM digital media marine source unit. RFX9900DM

Placeholder, no image available
Placeholder, no image available

FM/AM digital media marine source unit. RFX9900DM

FM/AM tuner with CD/DVD changer control and USB/SD playback.

Read More
0 Reviews
Discontinued
Overview Technologies Specifications Support Accessories
Overview

The RFX9900DM features a capacitive touch control panel with 7-line dot matrix display and Bluetooth streaming. The FM/AM stereo radio is SiriusXM ready and features USB/SD audio/video playback with CD/DVD control, Punch EQ and HDMI output.

FEATURES AT A GLANCE

  • US/European tuner
  • AM/FM with RDS
  • 1.8 DIN front with 1 DIN body
  • Stainless steel metal body
  • IPX6 front panel
  • Dual zone multi-source
  • Variable outputs: 2 rear, 2 front, 2 subwoofer
  • HDMI input/output
  • Optional RFX33SD includes USB, SD, iPod and Aux inputs
  • SiriusXM-Ready™ (SXi module)
  • Punch EQ
  • Front and rear IR input
  • 4 line text LCD
  • New software updateable
  • Optional wired remote
  • CD/DVD changer inputs
  • Optional iPod Connection (IPODEC cable sold separately)
  • 1 Year Warranty
Technologies
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Learn more
CD Playback

This source unit supports playback of CDs (Compact Discs).

Learn more
Wireless Bluetooth® Ready

Supports audio streaming via Bluetooth®.

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
SD/SDHC Playback

This source unit supports playback of media from an SD or SDHC media card.

Learn more
DVD Playback

This source unit supports playback of DVDs (Digital Video Discs).

Learn more
Specifications
FM TUNER
Frequency Range
87.5MHz - 107.9MHz
FM TUNER
Stereo Separation
30dB
FM TUNER
Signal-to-Noise Ratio
50dB
AM TUNER
Frequency Range
530kHz - 1710kHz
CD PLAYER
Signal-to-Noise Ratio
>60dB
CD PLAYER
Channel Separation
>60dB
RCA Output Voltage
3.6V (max)
RCA Output Impedance
10k Ohms
Operating Voltage
12V DC (10.8V - 15.6V)
Power Output
45 Watts x 4 @ 4-Ohms
FM TUNER
Sensitivity
2.8uV
AM TUNER
Usable Sensitivity
38dBuV
CD PLAYER
Frequency Response
20Hz - 20kHz
Speaker Impedance
4-Ohm or 8-Ohm
Fuse Rating
15A
Dimensions (HxWxD)
Chassis: 2.08" x 7.16" x 7.25" (53mm x 182mm x 184mm)
Faceplate: 3.5 x 8.0625" x 0.75" (88.9mm x 205mm x 19mm)
Shipping Weight-
5.20 Lbs. (2.35 Kg.)
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Return Authorization Process



Diagnose First

Prior to requesting an RA, try to diagnose the failure. Many products we receive are sent back with No Trouble Found, usually due to incorrect installation. Use our RFTECH:Knowledge Base for troubleshooting assistance.



Contact Customer Support

Please call us during normal business hours at 1-800-669-9899 (option #1) and be prepared with the following information:

  • First and Last Name with complete Shipping Address
  • Product Name (T0D415)
  • Serial Number (12 or 13 digit number)
  • Failure Diagnosis (no output, no power LED, etc.)
  • Scanned copy of Original Receipt emailed to [email protected] (dealer name, purchase date, and item purchased must be legible)
  • Credit/Debit Card (if paying for out-of-warranty claims)
  • No money orders or checks.


Shipping Instructions

When shipping your product, your package MUST have the following information:

  • RA# Printed Outside of Box (as large as possible)
  • Copy of Original Receipt


Shipping Address

Ship your product (UPS or FedEx preferred) to the following:


Rockford/ AJR International
300 Regency DR
Glendale Heights, IL 60139
RA#:_______________________
