Digital Audio/Video Player Black Box RFX5000

Placeholder, no image available
Placeholder, no image available

Digital Audio/Video Player Black Box RFX5000

Marine Hide Away Black Box AM/FM Stereo (RFXBT compatible)

Read More
0 Reviews
Discontinued
Overview Technologies Specifications Support Accessories
Overview

The RFX5000 is a "headless" digital audio/video player black box with AM/FM stereo tuner, USB/SD playback and Bluetooth streaming. Tuner features 6 AM and 18 FM presets with a switchable USA/Europe tuner. The audio section features bass/treble, balance, fader with an equalizer and mute. The optional RFXMR5BB controls this unit.

FEATURES AT A GLANCE

  • iPod playback with on-screen display
  • MP3/WMA Player
  • USB/SD music play
  • AM/FM stereo radio
  • Digital audio/video player
  • SiriusXM-Ready™ (requires SCC1 or SCVDOC1)
  • Aux Audio Input
  • Epoxy coated circuit board for water resistance
  • Subwoofer output
  • Video Input
  • 1 Year Warranty
Technologies
USB Playback

This source unit supports playback from a USB device.

Learn more
SD/SDHC Playback

This source unit supports playback of media from an SD or SDHC media card.

Learn more
SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Learn more
MP3 Playback

This source unit supports MP3 file format playback.

Learn more
WMA Playback

This source unit supports WMA file format playback.

Learn more
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
Wireless Bluetooth® Ready

Supports audio streaming via Bluetooth®.

Learn more
Specifications
FM TUNER
Frequency Range
87.5MHz - 107.9MHz
FM TUNER
Channel Step
200kHz
FM TUNER
Sensitivity
8dB
FM TUNER
Stereo Separation
30dB
FM TUNER
Signal-to-Noise Ratio
60dB
AM TUNER
Usable Sensitivity
32 dBuV
RCA Output Voltage
3 Volt (max)
Operating Voltage
13.8V DC (10 - 15.6V allowable)
Power Output
50 Watts x 4
Dimensions (HxWxD)
Chassis: 6-1/2" x 8" x 2-1/4"
AM TUNER
Frequency Range
530kHz - 1710kHz
RCA Output Impedance
33 Ohms
Speaker Impedance
4-Ohm or 8-Ohm
Fuse Rating
10A
AM TUNER
Channel Step
10kHz
AM TUNER
Signal-to-Noise Ratio
50dB
Shipping Weight-
3.4 Lbs. (1.54 Kg)
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Return Authorization Process



Diagnose First

Prior to requesting an RA, try to diagnose the failure. Many products we receive are sent back with No Trouble Found, usually due to incorrect installation. Use our RFTECH:Knowledge Base for troubleshooting assistance.



Contact Customer Support

Please call us during normal business hours at 1-800-669-9899 (option #1) and be prepared with the following information:

  • First and Last Name with complete Shipping Address
  • Product Name (T0D415)
  • Serial Number (12 or 13 digit number)
  • Failure Diagnosis (no output, no power LED, etc.)
  • Scanned copy of Original Receipt emailed to [email protected] (dealer name, purchase date, and item purchased must be legible)
  • Credit/Debit Card (if paying for out-of-warranty claims)
  • No money orders or checks.


Shipping Instructions

When shipping your product, your package MUST have the following information:

  • RA# Printed Outside of Box (as large as possible)
  • Copy of Original Receipt


Shipping Address

Ship your product (UPS or FedEx preferred) to the following:


Rockford/ AJR International
300 Regency DR
Glendale Heights, IL 60139
RA#:_______________________
