Prime 1200 Watt Mono Amplifier R2-1200X1
Prime 1200 Watt Mono Amplifier R2-1200X1
Primed for Performance, the R2-1200X1 is a 1200 watt, class-D amplifier, capable of operating at 4Ω, 2Ω or 1Ω mono. This amplifier is extremely efficient because of its Class-D technology which reduces demand on the vehicles electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases, and integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass. For subwoofers, a variable infrasonic filter and remote level control allows you to tune the bass for the desired level for the music.
Notify Me When Back In Stock:
The R2 models are developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.
FEATURES AT A GLANCE
- Balanced Differential Inputs with RCA Pass Through Outputs
- Variable Input Gain adjustment level
- Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
- High Level Input Capable
- Features C.L.E.A.N. Set-up
- Includes RLC Remote Level Control
- Top Mounted Control Panel
- Variable Infrasonic Filter
- Continuously Variable On Board Punch EQ
- Short Circuit & Over Current Protection
- Cast aluminum heat sink
- CEA-2006 Compliant & CE Compliant
- Class-D Topology
- Rollback Protection
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- 1 Year Warranty
R2 Amplifier Product Overview
Rockford Fosgate's R2 amplifiers are the building blocks for great audio systems, powerful enough to even DRIVE our Punch speakers and subwoofers. They have undergone an amazing upgrade by packing them with the latest features at an incredible value. Best of all, they are designed and engineered here in Tempe, Arizona.
Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...Learn more
Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.
High efficiency amplifier design that reduces current consumption from the charging system.Learn more
High efficiency amplifier design that reduces current consumption from the charging system.
Power supply circuit design that allows the amplifier to increase output power as voltage increases.Learn more
Power supply circuit design that allows the amplifier to increase output power as voltage increases.
Differential inputs eliminate noise picked up by signal cables.Learn more
Balanced Differential Inputs
Differential inputs eliminate noise picked up by signal cables.
C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help ...Learn more
C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help match a source to amp and optimize output.
MEHSA4 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.Learn more
MEHSA 4 (Maximum Efficiency Heat Sink Application)
MEHSA4 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.
During demanding musical conditions, the amplifier can dynamically reduce demand to prevent stress on the output ...Learn more
During demanding musical conditions, the amplifier can dynamically reduce demand to prevent stress on the output devices.
NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...Learn more
NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.
This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...Learn more
This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).
(Sum of Rated Power)
(RMS Continuous Power)
800 Watts x 1 @ 2Ω
1200 Watts x 1 @ 1Ω
889 Watts x 1 @ 2Ω
1389 Watts x 1 @ 1Ω
High-Level: 450 mV - 12 V
High-Level: 4-Pin Molex
(Pass-Thru active with RCA or Hi-Level input)
50 Hz - 250 Hz @ 12dB/Octave Butterworth
15 Hz - 40 Hz @ 12dB/Octave Butterworth
(4.9 cm x 17.3 cm x 28.5 cm)
