Prime 6" Component System R16-S

The Prime R16-S is a 6" 2-way component system rated at 40 watts RMS for a new generation of factory replacement speakers. Kit includes two woofers with grilles, two tweeters with integrated crossovers and mounting hardware.

Read More
0 Reviews
Discontinued
Overview Technologies Specifications Support Accessories
Overview

The Prime Series Component System is a new generation of factory replacement speaker delivering authentic Rockford Fosgate sound. The R16-S is a dedicated 2-way component system utilizing a Mica injected polypropylene cone for extended frequency response and accommodates direct OEM installation. The tweeter features a Mylar¨ balanced dome to reproduce crystal clear highs, an in-line crossover for simplifying installation, and accommodates flush, surface and angle mounting.

FEATURES AT A GLANCE

  • Mica-injected polypropylene cone
  • Foam surround
  • Stamped steel basket
  • 1/2" (13mm) Mylar® balanced dome
  • 1 Year Warranty
Technologies
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible speakers.

Learn more
CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Learn more
Specifications
Tweeter Size
(Nominal Diameter)
1.0" (25.4mm)
Speaker Type
Component System
Midrange Size
(Nominal Diameter)
6"
Crossover
Tweeter High-Pass (HP): 4.5kHz @ 6dB/octave
Tweeter Mounting Depth
1.06" (26.88 mm)
Mounting Hardware
Yes
Sensitivity
(dB @ 1W/1M)
89
Grille/Trim Ring Included
Yes
Power Handling (RMS)
40 Watts RMS
80 Watts Max
Shipping Weight
5 Lbs. (2.26 kg.)
Midrange Mounting Depth
1.97" (50.1 mm)
CEA-2031 Compliant
CEA-2031 Guidelines
Frequency Response (Hz)
60Hz - 20kHz
Nominal Impedance (Ohms)
4-Ohm
Compatibility
