Prime 150 Watt 2-Channel Amplifier R150X2

The PRIME R150X2 is a 2-channel amplifier that can pump-out 75 Watts into both channels at 2-Ohms, making it perfect for full-range or component speakers. The R150X2 can also run in bridged/mono mode for use with subwoofers.

• This model replaced by the R2-200X2

Read More
0 Reviews
Discontinued
Overview

Rockford Fosgate amplification at an unbelievable value. The R150X2 2-channel amplifier pumps out more than enough to power a set full-range or component speakers, or you can bridge it into a 4-ohm load to produce 150 watts for a single R1S410 10" or R1S412 12" woofer. Check out our RFTECH:Woofer WiringWizard to get the most out of your amplifier.

FEATURES AT A GLANCE

  • 12dB/octave Butterworth crossover
  • On-board Punch EQ with +18dB boost @ 45Hz
  • High Level Input (4-pin)
  • Real time output and power supply thermal sensing
  • RCA pass-thru outputs
  • Cast aluminum heatsink
  • MOSFET power supply
  • 4 Gauge power/ground connectors
  • Over current protection
  • Short circuit protection
  • Muted turn on
  • 1 Year Warranty
Technologies
CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
Class-A/B

An amplifier topology with the best of both worlds; a Class-A preamp and Class-B output stage.

Learn more
Specifications
Cta-2006 Compliant
Number of Channels
2
Total Power
(Sum of Rated Power)
150 Watts RMS
Rated Power
(RMS Continuous Power)
50 Watts x 2 @ 4-Ohm
75 Watts x 2 @ 2-Ohm
150 Watts x 1 @ 4-Ohm Bridged
Dynamic Power
(PVC/PowerCube®)
61 Watts x 2 @ 4-Ohms 0° Res
94 Watts x 2 @ 2-Ohms 0° Res
Bridgeable
Yes
Frequency Response
20Hz to 20kHz +/-1dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class A/B
Efficiency (average)
66% @ 4-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
High Level: 4-pin molex
Low Level: 1 RCA pair
Signal Output
Low Level: 1 RCA pair
Tone Controls
Punch Bass: 0dB to +12dB @ 45Hz
Crossover Controls
High-Pass/Low-Pass (HP/LP): 50-250Hz @ 12dB/octave Butterworth
Remote Controls
-
Visual Indicators
Power/Protect LED
Power Wire Gauge
4 AWG
Power Input Connector
Screw terminal
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Screw terminal
Cooling
Convection
Heatsink
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
20 A
Average Current Draw (13.8V Music)
10 A
Max. Current Draw (13.8V Sinewave)
20 A
Suggested Alternator
75 A
Included In The Box
Dimensions (H x W x D)
1.98 x 6.77 x 11.22 (in)
5 x 17.2 x 28.5 (cm)
Shipping Weight
6.6 Lbs. (2.99 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

The below diagrams optimize this amp for its lowest recommended BRIDGED/MONO load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
