Digital Media Receiver for Select 1998-2013 Harley-Davidson Models PMX-HD9813

Front View of Digital Media Receiver
Right Side View of Digital Media Receiver
Back Side View of Digital Media Receiver
Digital Media Receiver Installation View
Digital Media Receiver Installation View

Digital Media Receiver for Select 1998-2013 Harley-Davidson Models PMX-HD9813

Direct replacement digital media receiver for select 1998 - 2013 Harley-Davidson® motorcycles.  Features 3-inch full color, ultra-bright display with day/night modes and oversized buttons for easy control.  Engineered for the ultimate in performance and sound quality featuring 4-Volt pre-amp outputs that don't clip! Plug and play installation with OEM electrical system requires no additional wiring or cutting of existing factory harnesses or components.  Retains factory thumb controls. Refer to our COMPATIBILITY chart to verify fitment before purchasing.

PMX-HD9813 Overview
PMX-HD9813 H-D Road Glide Upgrade
Tuning Guide PMX-HD9813 Tuning Guide
Software Downloads PMX-HD9813 Software Downloads

Read More
3 Reviews
$599.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

Plug and play installation requires factory wiring harness and connectors in order to retain functionality.  Systems requiring rear speaker-line outputs will require additional harness (sold separately.) PMX source unit not compatible with factory amplified systems, CB, Intercom, rear volume controls, rear speakers on 1998-2005 Ultra’s, and factory equipped satellite radio systems. Estimated Installation Time: 1 HOUR.

FEATURES AT A GLANCE

  • Pandora® Internet Radio Control
  • A2DP and AVRCP Bluetooth® Wireless Streaming
  • 1998-2013 Harley-Davidson® direct replacement digital media receiver
  • Digital AM/FM/WB tuner with presets
  • USB Input with 1.5A USB Charging
  • SiriusXM® Ready (requires SiriusXM® SXV300 tuner)
  • 3" Full Color TFT Display with Day/Night Mode
  • Selectable HP/LP/AP Crossover with Selectable 12/24 dB/Octave Slope
  • Compatible with PMX-BTUR Remote control
  • Plug and Play Installation with OEM electrical connectors
  • AUX Input
  • Software updatable via USB
  • Retains factory thumb control functionality with no additional parts
  • Voltage gauge with Low voltage Warning
  • 7-Band Graphic EQ + PEQ
  • Multi-region radio frequencies
  • Independent Subwoofer Level Control
  • 2-Year Warranty
  • *Antenna not included
Videos
Technologies
ASTM D4329 UV Certified

Marine Grade standards ensure resistance to extreme environments.

Learn more
IPX4 Water Intrusion Rating

Protects from splashing water, no matter the direction.

Learn more
CISPR 25 Class 3 EMI Compliant

Vehicles, boats and internal combustion engines – Radio disturbance characteristics – Limits and methods of measurement ...

Learn more
FCC, CE RED, IC, and RCM Certified

Learn more
IPX6 Water Intrusion Rated

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Learn more
Bluetooth™ Audio Streaming

Wirelessly stream audio to your unit with any compatible Bluetooth® device.

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
SiriusXM Ready™

This radio is ready to accept SiriusXM programming.

Learn more
Element Ready™ | Motorcycle

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Specifications
Crossover
Sub-Out variable from 60 Hz - 120 Hz
Signal-to-Noise Ratio
RCA 2V: > 85 dB
High Level (CEA-2006): > 75 dB
Max Wrms: > 80 dB
Channel Separation
RCA: > 50 dB
High-Level: > 50 dB
Output Power
CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω MAX
≤1.0% THD+N
RCA Output Voltage
Front: 4 V Max
Rear: 4 V Max
Sub: 4 V Max
Frequency Response
RCA: 20Hz - 20 kHz
High-Level: 20Hz - 20 kHz
Idle Current
< 2 Amps
Operating Voltage
9.5 - 16 VDC
THD+N
4-Ohms: < 1.0 %
Output Impedance
< 500 Ohms
AM Tuner
Range: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 kHz
FM Tuner
Range: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response: 20 - 15 kHz
Bluetooth®
3.0+EDR
A2DP 1.3
USB Version
2.0
Supported Media Formats
MP3
WMA
USB Output Current
1.5A
Clock
Yes
USB Capacity
32 Gb max
255 Folders max
999 Songs max
Format Win USB as FAT32
Format Mac USB as MS-DOS (FAT)
Display Size:
Nominal Size: 3" Color TFT
Resolution: 960 x 240
Brightness: 380 nits
Contrast: 400
Pixels: 320 x 240
View Angle: 120
Made for iPhone Models
iPhone XS Max
iPhone XR
iPhone 8 Plus
iPhone 7 Plus
iPhone SE
iPhone 6s
iPhone 6
iPhone 5c
iPhone XS
iPhone X
iPhone 8
iPhone 7
iPhone 6s Plus
iPhone 6 Plus
iPhone 5s
iPhone 5
Shipping Weight
4.75 Lbs. (2.15 Kg)
Made for iPod Models
iPod touch (5th generation)
iPod touch (6th generation)
Dimensions
(HxWxD)
Faceplate: 2.7" x 8.4" x 0.7"
(68.4 mm x 213 mm x 17.1 mm)

Chassis: 2.5" x 8.2" x 7.5"
(63.5 mm x 209.3 mm x 191 mm)
Compatibility

Plug and play installation requires factory wiring harness and connectors in order to retain functionality.  Systems requiring rear speaker-line outputs will require additional harness available in the RFK-HD9813 or separately with the 1130-72997-01.

1 Not compatible with factory amplified systems, CB, Intercom, rear volume controls, rear speakers on 1998-2005 Ultra’s, and factory equipped satellite radio systems.



YEAR MAKE MODEL
2006-2013 Harley Davidson® Street Glide®1
1998-2013 Harley Davidson® Road Glide®1
1998-2013 Harley Davidson® Electra Glide®1
