PMX-5CAN

Punch Marine AM/FM/WB Multi-Zone Digital Media Receiver 2.7" Display w/ CANbus PMX-5CAN

The PMX-5CAN is an AM/FM/WB tuner and digital media receiver with 2.7" full color display with CAN bus functionality.  Features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using PMX-CAN.

Read More
0 Reviews
$299.99
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

The PMX-5CAN digital media receiver is designed for marine and motorsports systems.

The PMX-5CAN features a 2.7"full color TFT display for optimum viewing - even in full sun - that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such as SiriusXM and Pandora capabilities, Bluetooth audio steaming with album art support for Apple and Android products and true 2 zone/2 source control, this unit becomes a true command center of any system.

Output flexibility comes a 4x50W @ 2ohm internal amplifier or dual zone output RCA's allowing the addition of after-market amplifiers for more power and output. Add in the EEPROM memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you'll ever need. The PMX-5CAN also features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using the PMX-CAN adaptor (see Accessories tab.)

  • ISO8846/SAE J1171 Ignition Protection Certified
  • Stainless Steel Rear Chassis
  • Steering Wheel Control Interface Compatible
  • Pandora Internet Radio
  • SiriusXM-Ready™
  • A2DP and AVRCP Bluetooth Wireless Streaming
  • FCC, CE, IC, and C-Tick Certified
  • Multi Region Radio Frequencies
  • Low Voltage Warning Alert
  • AUX and USB Inputs with USB Charging
  • On Board Punch EQ Control
  • Independent Subwoofer Level Control
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • IPX6 Marine Grade for prevention of water intrusion
  • 7-Band Graphic EQ
  • 2.7" full color display w/ auto dimming backlightning
  • Zone Control: 2 Zone / 2 Source (F/R/S + F)
  • AM / FM / WB Tuner
  • CANbus (Controller Area Network) compatible. Requires PMX-CAN accessory
  • Compatible with a Multi-Function Display using NMEA2K entertainment standard. See our MFD Compatibility Chart
  • *Antenna not included
  • 2-Year Warranty
Technologies
Element Ready™ - Source Units

These source units are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
x
Element Ready™ - Source Units

These source units are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Learn more
x
SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Learn more
x
Pandora®

Pandora® (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service.

Built In Bluetooth®

Built In Bluetooth®

Learn more
x
Built In Bluetooth®

Built In Bluetooth®

Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
x
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Made for Android

This device supports the Google "Made for Android" protocol.

Learn more
x
Made for Android

This device supports the Google "Made for Android" protocol.

USB Playback

This source unit supports playback from a USB device.

Learn more
x
USB Playback

This source unit supports playback from a USB device.

ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

Learn more
x
ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

IPX6 Water Intrusion Rating

IPX6 Water Intrusion Rating

Learn more
x
IPX6 Water Intrusion Rating

IPX6 Water Intrusion Rating

CANbus

CANbus allows communication with other devices.

Learn more
x
CANbus

CANbus allows communication with other devices.

FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that ...

Learn more
x
FLAC

The Free Lossless Audio Codec is an audio format similar to MP3, but lossless, meaning that audio is compressed in FLAC without any loss in quality.

Specifications
Device Type
Digital-Media Receiver
Display Size
2.7” Color TFT
Frequency Response
20 Hz - 20 kHz
Power Output
CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω Peak
≤1.0% THD+N
Speaker Impedance
2-Ohms
Operating Voltage
10.5 V - 16 V
Fuse Rating
15 A
Compatible Remotes
PMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
Dimensions (HxWxD)
Width 8" (20.3cm)
Face Depth 1.5" (3.8cm)
Mount Depth 7.1" (18.2cm)
Height 3.5" (8.9cm)
Chassis to Face Top 0.9" (2.3cm)
Chassis to Face Bottom 0.59" (1.5cm)
FEATURES
N/A
SiriusXM-Ready®
(Yes/No)
Yes
Requires SXV300
Pandora® Internet Radio
(Yes/No)
Yes
Apple®/Android™ Compatible
(Yes/No)
Yes
Multi-Zone/Multi-Source
(Yes/No)
Yes
Speaker Outputs
(Yes/No)
Yes
USB Charging
(Yes/No)
Yes
AUX Input
(Yes/No)
Yes
Steering Wheel Control Ready
(Yes/No)
Yes
Clock
(Yes/No)
No
TUNER
N/A
TUNER
Number Of Presets
18 FM / 12 AM / 6 WB
FM TUNER
Frequency Range
87.9-107.9 MHz
FM TUNER
Sensitivity
8 dB
AM TUNER
Usable Sensitivity
40 dB
AM TUNER
Frequency Range
530 kHz - 1710 kHz
WB TUNER
Frequency Range
162.40 - 162.55
(US & Canada)
RCA OUTPUTS
N/A
RCA Frequency Response
87.5 MHz - 107.9 MHz
RCA Output Voltage
4V
RCA Output Impedance
500Ω
MEDIA PLAYER

MEDIA PLAYER
Audio Format Compatibility
MP3
WMA
FLAC
Made for iPod Models
iPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Made for iPhone Models
iPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
Android Compatibility
Bluetooth® Only
USB Capacity
32Gb max
999 Folders max
999 Songs max
USB Output Current
1A
USB Version
2.0
Compatibility
