Punch Marine Grade Media Receiver with 2.3" Dot Matrix Display PMX-1

The PMX-1 features a scratch resistant wet bonded display, superior Bluetooth® audio, AUX and USB inputs.  The Element Ready™ design also provides protection against water, dust, and UV rays.

Download RF Connect™ to control the PMX-1:
Download on the Apple App StoreGet It On Google Play

Software Downloads PMX-1 | Software Updates

Read More
0 Reviews
$329.99
Checking product inventory...
–+
–+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview Technologies Specifications Support Accessories
Overview

The PMX-1 features a 9H tempered glass screen optically bonded which allows for optimized viewing of the dot matrix display under all lighting and viewing conditions. The superior Bluetooth® audio features A2DP and AVRCP for better range, easier device pairing and glitch free wireless audio streaming. The flexible AUX and USB inputs enable convenient access to various audio playback formats and charging of your mobile devices.

FEATURES AT A GLANCE

  • 2-Year Warranty
  • FCC, CE and EN60945 Certified
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • AM/FM/WB Tuner
  • RF Connect iOS / Android App with native control of PMX-1
  • A2DP and AVRCP Bluetooth® Wireless Streaming
  • Voltage gauge with Low voltage Warning
  • 7-Band Graphic EQ + PEQ
  • Independent Subwoofer Level Control
  • Multi-region radio frequencies
  • Wet bonded 2.3" Full Dot Matrix LCD Display
  • 9H Tempered Glass Screen
  • Compatible with PMX-BTUR Steering Wheel Remote
  • IP6 Marine Grade Front Panel
  • AUX and USB Inputs with USB Charging
Technologies
Element Ready™ | Source Units

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Built In Bluetooth®

Built In Bluetooth®

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

Learn more
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
MP3 Playback

This source unit supports MP3 file format playback.

Learn more
Specifications
Multi-Zone/Multi-Source
(Yes/No)
No
Speaker Outputs
(Yes/No)
Yes
Bluetooth®
(Yes/No)
Yes
3.0+EDR, A2DP 1.3
TUNER
Number Of Presets
18 FM / 12 AM / 6 WB
Device Type
Digital-Media Receiver
Pandora® Internet Radio
(Yes/No)
No
Steering Wheel Control Ready
(Yes/No)
No
AUX Input
(Yes/No)
Yes (1 RCA pair)
SiriusXM-Ready®
(Yes/No)
No
Clock
(Yes/No)
No
Frequency Response
RCA: 20 Hz - 20 kHz
High-Level: 20 Hz - 20 kHz
USB Charging
(Yes/No)
Yes
Media Formats
MP3
WMA
FM Tuner
Range: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response. 20 - 15 KHz
AM Tuner
Range: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 KHz
FM Tuner
Range: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response. 20 - 15 KHz
AM Tuner
Range: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 KHz
Output Impedance
<500 Ω
Signal to Noise Ratio
RCA 2V: >85 dB
High-Level CEA-2006: >75 dB
High-Level Max Watts: >85 dB
Channel Separation
RCA: >70 dB
High-Level: >50 dB
Compatible Remotes
N/A
Max Output Voltage
RCA Front: 2 V
RCA Rear/Sub: 2 V
Max THD+N
High-Level: <1.0 @ 4-Ohm
USB Version
2.0
Idle Current
<2 A
Operating Voltage
9 - 16 VDC
USB Output Current
1 A
Fuse Rating
20 A
Shipping Weight
1.22 Lbs. (0.55 Kg)
Dimensions
Width: 4.5" (11.5 cm)
Face Depth: 1.5" (3.8 cm)
Mount Depth: 3.38 (8.6 cm)
Height: 4.2 (10.6 cm)
Back Panel Cutout
3" (77 mm)
Compatibility
Support

Knowledge Base Articles


Show all Knowledge Base topics

Ask Our Experts

EMAIL US

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Return Authorization Process



Diagnose First

Prior to requesting an RA, try to diagnose the failure. Many products we receive are sent back with No Trouble Found, usually due to incorrect installation. Use our Knowledge Base for troubleshooting assistance.



Contact Customer Support

Please call us during normal business hours at 1-800-669-9899 (option #1) and be prepared with the following information:

  • First and Last Name with complete Shipping Address
  • Product Name (T0D415)
  • Serial Number (12 or 13 digit number)
  • Failure Diagnosis (no output, no power LED, etc.)
  • Scanned copy of Original Receipt emailed to [email protected] (dealer name, purchase date, and item purchased must be legible)
  • Credit/Debit Card (if paying for out-of-warranty claims)
  • No money orders or checks.


Shipping Instructions

When shipping your product, your package MUST have the following information:

  • RA# Printed Outside of Box (as large as possible)
  • Copy of Original Receipt


Shipping Address

Ship your product (UPS or FedEx preferred) to the following:


Rockford/ AJR International
300 Regency DR
Glendale Heights, IL 60139
RA#:_______________________
