700 Watt Class-bd Mono Amplifier P700-1bd

The Punch P700-1bd is a mono amplifier capable of 700 Watts into a 1-Ohm load. The Class-BD technology produces bass more efficiently over traditional amps, and its frequency response allows it to be optimized for subwoofers.

Read More
1 Review
Discontinued
Overview

The Punch P700-1bd mono amplifier is specifically designed for medium to high-powered subwoofer applications. The variable crossover and built-in Punch EQ allow precision tuning of Bass, and the infrasonic filter keeps subsonic frequencies from damaging subwoofers. The Pass-Thru RCA jacks provide flexibility as your system grows and keeps Y-adapters to a minimum. This amplifier combines the efficiency of Class-D with the power of Class B and is perfect for running any subwoofer system.

  • 12dB/octave Butterworth crossover
  • MOSFET power supply
  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • Audiophile grade speaker connections
  • Top Mounted LED Indicators
  • RCA pass-thru outputs
  • Infrasonic filter
  • 1 Year Warranty
Technologies
Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Learn more
x
Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more
x
Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.

Class BD
Class BD

Class BD amplifiers have 75-80% efficiency ratings vs. 20-60% efficiency ratings of traditional class A/B amplifiers.

Learn more
x
Class BD
Class BD

Class BD amplifiers have 75-80% efficiency ratings vs. 20-60% efficiency ratings of traditional class A/B amplifiers.

CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
x
CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.

TO-247 MOSFETs
TO-247 MOSFETs

(left-OLD | right-NEW)
Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more ...

Learn more
x
TO-247 MOSFETs
TO-247 MOSFETs

(left-OLD | right-NEW)
Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more metal tab area for more power capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in competitor amps.

DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

Learn more
x
DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more
x
DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.

MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

Learn more
x
MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Learn more
x
NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.

Punch EQ2
Punch EQ2

Onboard equalizer with up to +18dB @ 45Hz and/or up to +12dB boost at 12kHz.

Learn more
x
Punch EQ2
Punch EQ2

Onboard equalizer with up to +18dB @ 45Hz and/or up to +12dB boost at 12kHz.

Specifications
CEA-2006 Compliant
CEA-2006 Guidelines
Number of Channels
1
Total Power
(Sum of Rated Power)
700 Watts RMS
Rated Power
(RMS Continuous Power)
225 Watts x 1 @ 4-Ohm
450 Watts x 1 @ 2-Ohm
700 Watts x 1 @ 1-Ohm
Dynamic Power
(PVC/PowerCube®)
328 Watts x 1 @ 4-Ohms
533 Watts x 1 @ 2-Ohms
773 Watts x 1 @ 1-Ohm
Bridgeable
No
Frequency Response
20Hz to 250Hz +/- 1.0dB
Input Sensitivity
Circuit Topology Class
Class BD
Efficiency (average)
84.7% @ 4-Ohm
80.5% @ 2-Ohm
Total Harmonic Distortion (Thd+Noise)
Signal Input
Low level: 1 RCA pair
Signal Output
Low level: 1 RCA pair
Tone Controls
Punch EQ2 Bass: 0dB to +18dB @ 45Hz
Crossover Controls
High-Pass (LP): 35Hz-250Hz 12dB/octave Butterworth
Remote Controls
Optional PEQ Remote Punch EQ
(overrides built-in Punch EQ2)
Visual Indicators
Power
Thermal
Protect
Power Wire Gauge
4 AWG
Power Input Connector
Block
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Screw terminal barrier strip
Cooling
Convection
Heatsink
Operating Voltage
Recommended Fuse
(Not Included)
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
Suggested Alternator
Dimensional Diagram
Dimensions (H x W x D)
2.25 x 7.625 x 10.25 (in)
5.71 x 19.37 x 26.03 (cm)
Shipping Weight
9.06 Lbs.
(4.11 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.





















Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Reviews

Amazing deep bass

I purchased a Toyota FR-S in 2015 that had this amp with a remote switch pre-wired in, and Rockford speakers all around, 9 in total. Usually I’m not too picky about the sound but coming from a cramped-for-space mini-truck, it was nice to finally have a little more bass. I have the gain set at 3 and I rarely turn the remote eq past 1, unless I want to shake everyone else’s windows, in which case I’ll turn it up to 3 or 4. Past that, it’s just too much for my ears in this interior. Its set to 250 RMS, which is perfect for this car. No problems yet, and I’ve owned it almost 2 years.

5.0
