Punch 300 Watt Full-Range Mono Amplifier P300X1

The Punch P300X1 is a mono amplifier capable of producing 300 Watts into a 2-Ohm load. The P300X1 full-range frequency response makes it perfect for a subwoofer system or for powering a dedicated center channel speaker.

Read More
1 Review
$199.99
+
Overview

The P300X1 is perfect for use as a dedicated subwoofer or center channel amplifier. Regardless if you're driving multiple speakers or just one, the hefty 2-ohm capability will deliver the right amount of PUNCH that you want! Now, thanks to its small chassis design, it will also fit where traditional amplifiers cannot.

  • High level input capable with Auto Turn-On circuit
  • RCA pass-thru outputs
  • Features C.L.E.A.N. Set-up
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • 12dB/octave Butterworth crossover
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • 1 Year Warranty
Technologies
CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
x
CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.

TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the ...

Learn more
x
TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the signal to travel through the amplifier at a lower voltage. The result is greater reliability and exceptional sound quality.

CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
x
CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).

Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Learn more
x
Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

Learn more
x
DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more
x
DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.

MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

Learn more
x
MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Learn more
x
NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.

Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more
x
Engineered In The USA
Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.

C.L.E.A.N. Set-Up
C.L.E.A.N. Set-Up

Patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Learn more
x
C.L.E.A.N. Set-Up
C.L.E.A.N. Set-Up

Patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Specifications
CEA-2006 Compliant
CEA-2006 Power Rating
200W x 1 @ 4Ω
≤1.0% THD+N
Number of Channels
1
Total Power
(Sum of Rated Power)
300 Watts
Rated Power
(RMS Continuous Power)
200 Watts x 1 @ 4-Ohm
300 Watts x 1 @ 2-Ohm
Dynamic Power
(PVC/PowerCube®)
260 Watts x 1 @ 4-Ohms 0° Res
444 Watts x 1 @ 2-Ohms 0° Res
Bridgeable
No
Frequency Response
20Hz to 20kHz +/- 1.0dB
Input Sensitivity
150 mV - 12 V
Circuit Topology Class
Class A/B
Efficiency (average)
74% @ 4-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Hi/Low level: 1 RCA pair
Signal Output
Low Level: 1 RCA Pair
Tone Controls
Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or
Punch EQ2 Treble: 0dB to +12.5dB @ 12kHz
Function depends upon LP/AP/HP switch position
Crossover Controls
High-Pass: 50Hz-250Hz @ 12dB/octave Butterworth
Low-Pass: 50Hz-250Hz @ 12dB/octave Butterworth
All-Pass: Yes
Remote Controls
Optional Punch Level Control (PLC2) Ready
Visual Indicators
Power/Protect/Thermal LED
Input Clip LED3
Output Clip LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Power Wire Gauge
8 AWG to 4 AWG
Power Input Connector
Captive C-Clamp
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Captive C-Clamp
Cooling
Convection
Heatsink
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
50 A
Average Current Draw (13.8V Music)
23 A
Max. Current Draw (13.8V Sinewave)
45 A
Suggested Alternator
75 A
Dimensional Diagram
Dimensions (H x W x D)
2.38 x 7.76 x 9.86 (in)
6.05 x 19.71 x 25.04 (cm)
Shipping Weight
9.5 Lbs. (4.30 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.























Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Wiring Kits

ARE YOU ENGINEERED TO ROCK?

Get a 1-Year extended amplifier warranty when using a matching Rockford Fosgate installation kit.

We want you to get the maximum performance and reliability from your Rockford Fosgate amplifier. We're so certain using the right cables make a difference, we'll give you and additional 1-Year amplifier warranty when using a matching installation kit!

  • 1 Purchase a Rockford Fosgate Punch or Power amplifier.
  • 2 Add the correct amplifier installation kit.
  • 3 Get an additional 1 year amplifier warranty FREE!

Reviews

Back like the 90s

Great amp real clean only dislike no sub Sonic filter in the past years have use zapco arc,ppi,us acoustics,mmats,us amps and I have to say this amp is really nice big upps to Rockford

4.0

1 Review
