M2D2-12I

M2 12" DVC 2Ω Color Optix™ Infinite Baffle Marine Subwoofer M2D2-12I

The M2D2-12I Color Optix™ 12” DVC 2-Ohm infinite baffle subwoofers deliver loud, clear, accurate bass, and light the way for your journey! M2 provides a customized look by using either the stainless-steel grille or the white “sport” grille inserts. The subwoofers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IP67 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential. This subwoofer is optimized for Infinite Baffle installations, where an enclosure is not required.

Read More
0 Reviews
NEW
$449.99
+
Overview

The M2 series of Element Ready™ subwoofers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To compliment the plug and play connectivity and streamline installation, M2 subwoofers are equipped with a VersaSwitch™ to make changing impedance between 1 and 4 ohms as easy as flipping a switch. This subwoofer is optimized for Infinite Baffle installations, where an enclosure is not required. A mounting baffle is required to isolate any interaction between the front and rear wavelengths to prevent cancellation.

  • Element Ready™ design protects lighting from exposure
  • Adjust color experience to suit your taste with Rockford Fosgate® Color Optix™ controller (optional)
  • Bright, wide-angle LEDs provide rich, reliable illumination
  • Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
  • Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
  • VERSA impedance switch quickly allows series or parallel configuration without additional wiring
  • 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
  • Gold plated Marine grade brass connection terminals provide a corrosion resistant, maintenance free connection
  • Deutsch DT connectors incorporate a front and rear silicone sealing system to protect against environmental ingress
  • 2-piece grille allows for interchangeable stainless-steel or "sport" option
  • Optimized for infinite baffle applications when an enclosure is not an option
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • Provides superb low and midrange frequency reproduction with smooth high frequency roll-off
  • VAST vertical attach surround technique increases effective radiating cone area up to 25%
  • Klippel Verified certification program delivers the best possible speakers
  • IPX6 Rated
  • 2-Year Warranty
Videos

Color Optix™ Experience

Experience the Color Optix™ speaker and subwoofer line from Rockford Fosgate. Designed for watercraft of all kinds, they are Element Ready to withstand water, salt, and UV rays.

Color Optix™ Speakers Overview

In this video, we'll break down our all-new Color Optix™ speakers and subwoofers, that are designed to light the way.

Color Optix™ Controller Overview

The PMX-RGB Color Optix™ controller provides LED lighting control over M1 & M2 speakers and subwoofers. This allows you to create a true marine ecosystem that works together seamlessly. Pair this with our RF Connect™ smartphone app and give your system infinite control by customizing the color and lighting effects of your speakers. Supports up to 8 speakers or subwoofers. App supports multiple Color Optix™ controllers.

Technologies
Color Optix™ Control
Color Optix™ Control

Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play ...

Learn more
x
Color Optix™ Control
Color Optix™ Control

Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play controller and App (sold separately.)

Element Ready™ - Subwoofers
Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

Learn more
x
Element Ready™ - Subwoofers
Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

True Marine Ecosystem
True Marine Ecosystem

Dual Integrated Deutsch™ and Amphenol™ connections provide industry leading marine plug-and-play connectivity and flexible install options

Learn more
x
True Marine Ecosystem
True Marine Ecosystem

Dual Integrated Deutsch™ and Amphenol™ connections provide industry leading marine plug-and-play connectivity and flexible install options

VERSA Switch
VERSA Switch

Allows you to easily switch Dual Voice Coils into a Series or Parallel configuration.

Learn more
x
VERSA Switch
VERSA Switch

Allows you to easily switch Dual Voice Coils into a Series or Parallel configuration.

VAST Surround - Marine
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
x
VAST Surround - Marine
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Klippel Verified
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
x
Klippel Verified
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

IPX6 Water Intrusion Rating
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

Learn more
x
IPX6 Water Intrusion Rating
IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
x
CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).

ASTM B117 Testing
ASTM B117 Testing

ASTM B117 500Hr Salt/Fog Testing Standards

Learn more
x
ASTM B117 Testing
ASTM B117 Testing

ASTM B117 500Hr Salt/Fog Testing Standards

ASTM G154 Testing
ASTM G154 Testing

ASTM G154 500Hr Accelerated UV testing

Learn more
x
ASTM G154 Testing
ASTM G154 Testing

ASTM G154 500Hr Accelerated UV testing

ISO60068-2-64 Testing
ISO60068-2-64 Testing

ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on watercraft ...

Learn more
x
ISO60068-2-64 Testing
ISO60068-2-64 Testing

ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on watercraft and motorsport applications.

Specifications
Size
12"
Nominal Impedance (Ohms)
1-Ohm or 4-Ohm Switchable
Power Handling (Watts RMS)
400 Watts RMS
1,600 Watts PEAK
Voice Coil Type
Dual Voice Coil
Voice Coil Diameter
1.95" (49.53 mm)
Magnet Weight (oz)
61.09 oz. (1.7 Kg)
Frequency Response (Hz)
20 Hz - 750 Hz
Fs (Hz)
38
Re (Ohms)
3.3
Le (mH)
3.43
Sd (cm2)
539
Qms
4.7
Qes
1.04
Qts
0.85
Vas
64
SPL (dB @ 1w/1m)
88
SPL (dB @ 2.8v)
90
Xmax (mm)
15
Woofer Displacement
0.121 (3.43 Liters)
Speaker Connector
2-pin Deutsch™ and 1/8" Spade
Cutout Diameter
11” (279.4 mm)
Mounting Depth
5.13" (130.4 mm)
Shipping Weight
14.26 Lbs. (6.47 Kg)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
