M2 200 Watt 2-Channel Element Ready™ Amplifier M2-200X2

Designed to withstand the elements, the M2-200X2 Element Ready™ amplifier is a 200 watt, full-range class-D model, capable of operating at 4Ω or 2Ω stereo, and 4Ω bridged/mono. This amplifier is extremely efficient because of its class D technology which reduces demand on the electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases.

Read More
0 Reviews
$269.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

The M2 Series were developed for marine audio environments that feature UV resistant protection and special internal conformal coating that protect the electronics from water. It’s designed for those who want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of M2 Series amplifiers are also designed to be easy to setup and configure, making them perfect for use in any application.

FEATURES AT A GLANCE

  • UV stable powder coated cast aluminum heatsink
  • Element Ready™ design protects against outdoor exposure
  • Zinc Nickel-plated Marine grade brass connection terminals
  • Optimized using AudioGraph PowerCube measurement tool
  • Conformal coated circuit board protects against dust and water
  • C.L.E.A.N. input/output clip detection and indicator LEDs
  • RATS (Rockford Automated Testing System) proprietary quality & performance tested
  • Low Impedance Stability
  • Integration with OEM and Aftermarket Radios
  • Balanced Differential Inputs eliminates noise picked up by signal cables
  • Integrated Power and Speaker Terminals
  • Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
  • 2-Year Warranty
  • RCA pass-thru outputs
  • Variable Infrasonic Filter
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • Top Mounted Control Panel
  • Short Circuit & Over Current Protection
  • CEA-2006 Compliant & CE Compliant
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • "Auto-Sense" turn-on with remote out (high level in)
Videos
Technologies
Element Ready™ | Amps

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
C.L.E.A.N. Set-Up

C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with in/out clip LEDs to help ...

Learn more
P.O.W.E.R.

Power supply circuit design that allows the amplifier to increase output power as voltage increases.

Learn more
Full Range Class-D

A full-range version of the Class-D topology which is a high efficiency amplifier design that reduces ...

Learn more
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Learn more
MEHSA 4 (Maximum Efficiency Heat Sink Application)

MEHSA4 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

Learn more
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
Specifications
Cta-2006 Compliant
Number of Channels
2
Total Power
(Sum of Rated Power)
200 Watts
Rated Power
(RMS Continuous Power)
50 Watts x 2 @ 4Ω
100 Watts x 2 @ 2Ω
200 Watts x 1 @ 4Ω Bridged/Mono
Dynamic Power
(PVC/PowerCube®)
60 Watts x 2 @ 4Ω
107 Watts x 2 @ 2Ω
215 Watts x 1 @ 4Ω Bridged/Mono
Bridgeable
Yes
Frequency Response
20 Hz - 20 kHz
Input Sensitivity
Low-Level: 150 mV - 4 V
High-Level: 450 mV - 12 V
Circuit Topology Class
Class D
Efficiency (average)
Total Harmonic Distortion (THD+Noise)
4Ω: <1.0%
2Ω: <1.0%
Signal Input
Low-Level: 2 RCA
High-Level: 4-Pin Molex
Signal Output
Low-Level: 2 RCA
(Pass-THru active with RCA or Hi-Level input)
Tone Controls
No
Crossover Controls
High-Pass:
50 Hz - 250 Hz @ 12dB/Octave Butterworth
Low-Pass:
50 Hz - 250 Hz @ 12dB/Octave Butterworth
All-Pass: Yes
Remote Controls
No
Visual Indicators
Power/Protect
C.L.E.A.N. In
C.L.E.A.N. Out
Power Wire Gauge
4 AWG
Power Input Connector
Compression Terminal Block
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Compression Terminal Block
Cooling
Convection
Heatsink
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
30 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
18 A
Suggested Alternator
Included In The Box
Dimensions (H x W x D)
1.9" x 6.8" x 8.1"
(4.9 cm x 17.3 cm x 20.5 cm)
Shipping Weight
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

When running subwoofers, the below diagrams produce optimum power when bridging into a 4-ohm load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
