2014+ Harley-Davidson® Road Glide® CVO® & Street Glide® CVO 6 Speaker & Amp Kit (Gen-2) HD14CVO-STAGE3

Front View of Amplifier
Front View of Products Included in Kit
Three Quarter Beauty Shot of Speakers
Stage 3 Kit Installation View on Street Glide
Front View of Stage 3 Kit
Stage 3 Kit Installation View on Road Glide
Three Quarter Beauty Shot of Products Included in Kit

2014+ Harley-Davidson® Road Glide® CVO® & Street Glide® CVO 6 Speaker & Amp Kit (Gen-2) HD14CVO-STAGE3

Add a high-performance 6-speaker, 400-watt audio system to your motorcycle, purpose built for select 2014+ Harley-Davidson® CVO Road Glide® and CVO Street Glide® models. System includes a two 6.5” speakers for the upper fairing, two 6.5” speakers for the lowers, two 5x7” speakers for the saddlebags, a 400 watt 4-channel amplifier, and complete installation kit. You will need to flash your factory radio to use this kit. Ready to flash? Here’s a list of dealers that can flash your radio. Refer to our COMPATIBILITY chart to verify fitment before purchasing.

2014+ H-D CVO Street Glide Stage-3 Installation

• This product replaced by HD14CVO-STG2 + TMS65

Read More
0 Reviews
Discontinued
Overview

This 6-speaker, 400 watt high performance audio system is designed for select 2014+ Harley-Davidson® motorcycles (see compatibility chart.) The included 6.5” upper/lower fairing speakers and 5x7” saddlebag lid speakers are frequency-response tuned to overcome wind, exhaust, and road noise up to 75 MPH. The 400-watt amplifier features 2-channels for the upper/lower fairing speakers and 2 channels for the rear baglid speakers. The amplifier installation kit includes an external heat-sink, mounting brackets, speaker and power wiring with all necessary hardware. The included T-harness integrates into the electrical system for front/rear fading capability (requires Rockford Fosgate flash) and features a loop-thru for an optional DSR1 digital signal processor (sold separately.) Supplied with factory amplifier bypass plugs. You will need to flash your factory radio to use this kit. Ready to flash? Here’s a list of dealers that can flash your radio. Refer to our COMPATIBILITY chart to verify fitment before purchasing.

FEATURES AT A GLANCE

  • 2-Year Warranty
  • No drilling or cutting required
  • Direct connect wiring harnesses for Harley-Davidson® models
  • Kits bolt to factory attachment points
  • TM400X4ad Power Marine 400 Watt Class-ad 4-Channel Amplifier
  • Factory Harley-Davidson® Boom!™ Box 4.3, 6.5GT, and GTS must be flashed to use this kit
  • T-harness supports front/rear fader (requires flash: "Rockford Fosgate 2014+ All Bikes")
  • RFK-HD14 2014+ Harley-Davidson® Road Glide® & Street Glide® Amplifier Wiring Kit
  • TMS57: Factory replacement 5"x7" 2-way speaker with integrated phase-aligned 25 mm tweeter
  • Includes lower fairing speakers (must be non-water cooled)
  • TMS65: 6.5" 2-way Element Ready™ speaker with integrated phase-aligned 25 mm tweeter
Technologies
CEA-2006 (amplifier)

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
Element Ready™ | Motorcycle

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
CEA-2031 (speakers)

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Learn more
Specifications
Shipping Weight
25.3 Lbs (11.47 Kg)
Speaker Qty
6
Amplifier Type
External
Mounting Hardware
Yes
Total Power
400 Watts
Grille/Trim Ring Included
Yes
Included In The Box
(4) TMS65 Speakers
(4) 2015+ Road Glide Grilles
(4) 2014+ Street Glide Grilles
(4) 2014+ TourPak Grilles
(2) 5x7” Speakers
(2) 5x7” Rebadge Logos
(1) TM400X4ad Amplifier
(1) RFK-HD14 Amp Mounting Kit
(5) Factory Amp Bypass Plugs
(1) DSR1 Loop-Thru Harness
(2) Amp Output Y-Adaptors
(1) Wiring Harness Kit
(1) Hardware Pack
Compatibility
YEAR MAKE MODEL CHASSIS FAIRING
2018–2020 Harley-Davidson® CVO Street Glide® (6-speaker)1, 2 FLHXSE Bat Wing

1 Requires factory Harley-Davidson® radio to be flashed. Read more here.
2 Saddlebag kit compatible only with ABS plastic lids. Not compatible with Fiberglass lids.

Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.
