Punch Marine 6.5" Full Range Speakers - Luxury PM2652X

The PM2652X is a Punch 6.5" 2-way component system with a coaxially mounted tweeter featuring marine grade weather proofing technologies. Supplied in all white with a UV stable centrex injection molded plastic grille.

Read More
0 Reviews
Discontinued
Overview

The PM2652X 6.5" Element Ready speaker is the perfect choice for your ride whether hitting the lake or the trails. This marine grade speaker features a 1" aluminum dome tweeter designed for high output and sonic clarity and is coated to protect it against the elements and UV radiation, preventing it breaking down over time. The tweeter is bridge mounted over the midrange cone giving the speaker a component quality sound and allowing for a full cone midrange driver.

The midrange is made of a mineral filled, injection molded polypropylene material and features integrated UV inhibitors protecting it from sun exposure.This is attached to the UV stable, Centrex® plastic, injection molded frame assembly by a Thermo-Plastic Elastomer (TPE) surround designed for maximum cone control and excursion. It too has been treated for UV radiation and salt-fog resistance for maximum lifespan. The cone also attaches to a moisture, fatigue and tear resistant Aramid fiber spider for additional linear control while being driven by our high excursion, matched motor magnetics structure with IDHS which improves power handling.

Additionally, the speaker features fully insulated flex lead wires, corrosion resistant gold plated speaker terminals with integrated expansion connections for our PM2T-S tweeter kit and a fully sealed 12dB/ Octave crossover. The entire system is topped off with a UV Stable Centrex® plastic grill assembly with stainless steel hardware.

FEATURES AT A GLANCE

  • Moisture, tear and fatigue resistant Aramid fiber spider
  • Integrated aluminum heat sinking shortening ring (IDHS)
  • Available in white only
  • UV stable Centrex™ 814 injection molded plastic parts
  • Fully insulated flex lead wire stitched under spider
  • Spare terminal set for optional additional tweeters
  • UV and Salt-Fog resistant TPE (Thermo-Plastic Elastomer) surround
  • Linear, high excursion matched motor magnetics and suspension design
  • Integrated 12dB/octave sealed crossover with integrated protection circuit
  • 1" (25mm) bridge mounted component grade coated aluminum alloy tweeter
  • True Marine Grade compliance
  • Corrosion resistant gold plated polarized input terminals
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • 2-Year Warranty
Technologies
Element Ready™ | Speakers

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
ASTM Test Standards

Marine Grade standards ensure resistance to extreme environments.

Learn more
CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Learn more
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
FlexFit Basket - Marine

The slot mounted frame pattern allows fine-tuning of the marine speaker's mounting position.

Learn more
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
ICC Crossover

The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier ...

Learn more
Specifications
Nominal Impedance (Ohms)
4-Ohm
Midrange Mounting Depth
2.8 in. (7.1 mm)
Speaker Type
2-Way Coax
Power Handling (RMS)
85 Watts RMS
170 Watts Max
Crossover
High-Pass (HP): 12dB
Frequency Response (Hz)
49Hz - 22kHz
Shipping Weight
Sensitivity
(dB @ 1W/1M)
89
Grille/Trim Ring Included
Yes
Mounting Hardware
Stainless Steel
Midrange Size
(Nominal Diameter)
6.5"
CEA-2031 Compliant
CEA-2031 Guidelines
Tweeter Size
(Nominal Diameter)
1" (25 mm)
